RH-4609

200A DC ARC Welding Inverter

Write a review

Compare

Hot Sales

Download Catalog

Detailed Description

Features

- IGBT technology for better welding quality , greater welding penetration,reduced energy consumption and increased efficiency
- Unbeatable automatic short circuit current protection, easy ignition, less spark, provides excellent arc strike performance at rust suface
- Multi protection of over voltage, over heat, over current and over load protection
- Hot start, anti-stick, less spark, reliable. Ideal welding equipment for entry-level welder.
- Digital display provides highly accurate welding
- Professional cooling system in order to increase efficiency and continuance welding
- Equipped with full bridge inverter circuit and 5 boards technology

Specifications

Model

RH-4609

Input voltage

170V-250V

No-Load voltage

35-50V

Out-put Current Range

20-200A

Rated Out-put Voltage

20.8--28V

Max Input Power Capacity

9.2KVA

Max Input Current

41A

Power Factor

0.73

Duty-cycle (25°C)

100%

Insulation Class

Protection Class

IP21S

Electrode Diameter

1.6-5.0mm

Accessories

3m*20mm CCA cable with 300A holder 1pc, 2m*20mm CCA cable with 300A earth clamp 1pc, mask 1pc, brush 1pc, Strap 1pc
