Self priming pump 2HP
Model : RH-4025
: 0
Self priming pump 2HP
Self priming pump 2HP

Model : RH-4025 (NA)

Self priming pump 2HP

Bulk Order
 pump with compact dimensions and capable of generating high heads
Suitable for clean water and free of solids and abrasives, non-viscous, nonaggressive, non-crystallised and chemically neutral, clean liquids
Properly in domestic, small industrial ,irrigation of gardens and allotments usage
Provides with Thermal protector and insulation Class B to ensure motor long life
ability for suction up to 8m
More efficiency by using Ceramic/Graphite mechanical seal, brass impeller cast iron pump housing
Model RH-4025
Power 2Hp
Voltage 220-240V
Frequency 50-60Hz
Min.Flow 2.4m³/h
Max. Flow 9.6m³/h
Min.Head 3m
Max. head 48m
Inlet/outlet port diameter 11/4X1 In
Suction heigh 8m
Speed 2850RPM
Max. liquid temperature ℃60
Max. Ambient temperature ℃40
Working Pressure 4.8BAR
Protection level IP44
Insulation Class B
Pump housing material CAST IRON
Motor housing material ALUMINUM
Mechanical seal material Ceramic/Graphite
Motor protection WITH
Coil winding material COPPER
Impeller material BRASS
shaft material 316+45
Weight 26.2Kg
Supplied in honeycomb carton
