Model : RH-4037 (NA)
Model | RH-4037 |
Power |
750 W 1 HP |
Voltage | 220-240 V |
Frequency | 50 Hz |
Max. Flow |
12500 L/h 12.5 m³/h |
Min.Head | 0 m |
Max. head | 8.5 m |
outlet port diameter | G1 1/2 inch |
Speed | 2850 RPM |
Max. liquid temperature | 35 ℃ |
Max. Ambient temperature | 35 ℃ |
Working Pressure | 0.85 Bar |
solid passage diameter | 5 mm |
max immersion depth | 7 m |
max dry running time | 30 seconds |
Protection level | IPX8 |
Insulation Class | B class |
Pump housing material | PP |
Motor housing material | 409#Stainless steel |
Mechanical seal material | Ceramic and graphite |
Motor protection | 125 ℃ |
Coil winding material | copper winding |
Impeller material | PA66 |
shaft material | 420#Stainless steel |
Net Weight | 5 Kg |
Gross weight | 5.4 Kg |
packaging | color box |
Accessories | Adaptor*1, manual*1 |
