SDS Max 3-Cutter Hammer Drill Bit 14*540- German
Model : RH-59253
: 0
SDS Max 3-Cutter Hammer Drill Bit 14*540- German
SDS Max 3-Cutter Hammer Drill Bit 14*540- German
SDS Max 3-Cutter Hammer Drill Bit 14*540- German
SDS Max 3-Cutter Hammer Drill Bit 14*540- German
SDS Max 3-Cutter Hammer Drill Bit 14*540- German
SDS Max 3-Cutter Hammer Drill Bit 14*540- German

Model : RH-59253 (NA)

SDS Max 3-Cutter Hammer Drill Bit 14*540- German

Bulk Order
  • The Trijet Ultimate SDS-max hammer drill bit is even more robust and faster than its predecessor.
  • Pronounced, patented double centring tip ensures simple, precise positioning
  • In total, the Trijet Ultimate therefore is 4 x more robust as well as 10% quicker in concrete and 35% quicker in reinforcement, resulting in a very long service life with up to 1.500 holes drilled.
  • Cutting edges of equal height with reverse curvature, the newly developed cutting geometry with reinforcement protection chamfers, reduced frontal surfaces and the optimised helix guarantee even better performance, making the Trijet Ultimate our best hammer drill bit.
The RH-59253 is built for efficient and powerful drilling. This 14mm drill bit is 4x more robust and drills 35% faster in reinforced concrete compared to previous models. With its heat-resistant construction and patented double-centering tip, it offers improved control and precision, while supporting a service life of up to 1500 holes.
Model RH-59253
size 14 mm
No of Flute 3
Overall Length 540 mm
Working Length 400 mm
Material Steel
Tip Material Tungsten Carbide
Surface Finish Shotpeened
Hardness >48 HRC
Temprature Strength 1200 °C
Weight 518.4 gr
Packaging Clip
Downloads & Resources
Need more information to discover the features of Ronix RH-59253? So, keep reading!
The RH-59253 is made from high-quality steel and equipped with a durable Tungsten Carbide tip that can withstand temperatures up to 1200°C. The 3-flute design and optimized helix help remove dust efficiently, while the advanced cutting geometry protects the bit when it comes into contact with reinforcement. In addition, its shot-peened surface improves wear resistance, and the hardness is above 48 HRC.
This Trijet Ultimate drill bit is suitable for drilling into concrete and reinforced concrete. It is 10% faster in concrete and 35% faster in reinforcement. These features contribute to a very long service life, allowing up to 1500 holes with consistent performance.
This model has a 14mm diameter, with an overall length of 540mm and a working length of 400mm, making it suitable for accurate drilling.
Weighing 518.4g and made from durable steel, the RH-59253 offers a strong and reliable structure. The patented double-centering tip ensures simple and precise positioning, helping prevent slipping when starting drilling.
The practical clip-style package of the Ronix RH-59253 keeps the drill bit secure and makes storage and transport easier.
