Model : RH-4784 (NA)
-460 cc, 4-stroke 10000 w engine with considerable performance
-25 Liter full steel fuel tank provides up to 6.5 hours of run time
-Special compact designfor ease of use and better portability
-Circuit breaker outlets for added protection
-Minimum sound and vibration in indoor usage
-100% copper-wound generator head allows continuous operation without overheating
-Includes one (12V) DC outlets
-Ideal for workshops and light-duty industrial usage
Many people think that generators are the kind of tools that produce electricity. But in fact, they convert mechanical energy into electrical energy needed by various devices. So, to prepare yourself for cases of emergency or stay warm and comfortable in a tent on cold nights, generators are must-have items.
Ronix RH-4784 is one of the best-in-class Gasoline Generators with a compact body design so that users can move it more easily. This widely used device is equipped with a single-cylinder and 4-stroke engine with an air-cooled system. This system increases the lifespan and strengthens the performance of the tool.
With its 7500W maximum output power, this generator can be your best companion in prolonged power outages. With minimum noise and vibration, this efficient machine best suits indoor spaces (with proper air conditioning) and workshop or light-duty industrial usage. It has a 25L full-steel fuel tank that provides up to 6.5 hours of run time.
Scroll down to find out about other features of the Ronix RH-4784 gasoline generator.
Model | RH-4784 |
Type | Gasoline Generator |
AC Voltage | 220V |
Generator rated amperage | 32A |
Frequency | 50Hz |
Max. Output | 7.5KW |
Rated Output | 7KW |
Power Factor | 1 |
DC Output | DC 12 V, 8.3A |
Engine model | FC192F |
Engine Type | "single cylinder , 4-stroke,forced air cooled" |
Engine Bore×Stroke | 92mm×69 mm |
Displacement | 460cc |
Max. Output ENGINE | 10KW / 3600rpm |
Fuel | Gasoline |
Fuel tank Capacity | 25Lit |
Rated Continuous Operation | 6.5hr |
Lubricating oil | SAE 10W-30 |
Lubricating oil Capacity | 1.1Lit |
Starting System | Recoil & E-start |
Ignition System | T.C.I |
Spark Plug: Type | F7TC/F7RTC |
Maximum fuel consumption rate | 3.85Lit/hr |
Net dimension | 686mm×516mm×560mm |
Overall dimension | 740mm×575mm×625mm |
Net Weight | 86Kg |
Gross weight | 88Kg |
Supplied In | carton |
Includes | "2Plug,1 Spark plug sleeve, 1 Rod,one 12V DC output clip,2 key, 1 set wheels and handles" |
Before buying any product, it is necessary to get enough information about its functions and features. Various factors, such as engine type, fuel tank, body design, generator type, voltmeter, circuit breaker, etc., are among the essential features that significantly impact generator performance.
To choose the best gasoline generator that suits your needs, you need to know what features and specifications these products offer. In the following, we give a detailed description of the Ronix RH-4784.
Ronix RH-4784 has a four-stroke air-cooled 7500W engine with an FC192F model number. The cylinder’s volume is 460CC, and the machine has a TCI ignition system along with a recoil and E-start starting system. The maximum output power is 10KW at 3600RPM. The lubricating oil type is SAE 10W-30 and is stored in a 1.1-liter oil capacity. The spark plug type is F7TC/F7RTC, and the maximum fuel consumption rate is 3.85Lit/hr.
The full-steel Fuel tank Capacity is 25L. Its fuel type is gasoline, providing up to 6.5 hours of run time.
The gasoline generator delivers an AC voltage of 220V, a rated amperage of 32A, and a frequency of 50 Hz, with a copper Winding for maximum effectiveness in long-term use. This generator has a maximum output power of 7.5kw and a rated output of 7kw. The DC output voltage is 12V/8.3A. It has a 100% copper-wound generator head, allowing continuous operation without overheating.
The body of this tool is made with a gross weight of 88kg and a net weight of 86kg. The net dimensions of the product are 686mm×516mm×560mm, and the overall dimensions are 740mm×575mm×625mm. It has minimum vibration and sound with a compact design. But to use it in indoor spaces, ensure you have ideal air conditioning.
It’s covered with circuit breaker outlets for added protection.
Ronix RH-4784 gasoline generator’s carton includes other accessories, including 2 Plugs, 1 Spark plug sleeve, 1 Rod, a 12V DC output clip, two keys, and 1 set of wheels and handles.
